GB X870E AORUS PRO X
428.08€ (837.25лв)
В наличност
GB X870 4xDDR5 4xSATA3 RAID HDMI 4xM2 GLAN 3xPCIEx16 WiFi... →
Характеристики
BIOS
1 x 512 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
WiFi скорост
2.5 Gbps, 100 Mbps
WiFi стандарт
802.11a
WiFi честота
2.4 GHz, 5 GHz, 6 GHz
Видео изходи
Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller:; - 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz; * Support for DisplayPort 1.4 version and HDR; Integrated Graphics Processor with AMD Radeon™ Graphics support:; - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz; * Support for HDMI 2.1 version, HDCP 2.3, and HDR.; ** Support for native HDMI 2.1 TMDS compatible ports.; - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz; * Support for HDMI 1.4 version
Видео карта, серия
Radeon Graphics
Входове/изходи
iTE® I/O Controller Chip
Конектори
1 x 24-pin ATX main power connector; 2 x 8-pin ATX 12V power connectors; 1 x PCIe power connector; 1 x CPU fan header; 1 x CPU fan/water cooling pump header; 4 x system fan headers; 2 x system fan/water cooling pump headers; 3 x addressable RGB Gen2 LED strip headers; 1 x RGB LED strip header; 4 x SATA 6Gb/s connectors; 4 x M.2 Socket 3 connectors; 1 x front panel header; 1 x front panel audio header; 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support; 2 x USB 3.2 Gen 1 headers; 2 x USB 2.0/1.1 headers; 1 x noise detection header; 1 x HDMI port (Note); 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only); 2 x temperature sensor headers; 1 x reset jumper; 1 x Clear CMOS jumper; Back Panel Connectors; 1 x HDMI port (Note); 1 x reset button; 1 x power button; 1 x Clear CMOS button; 1 x Q-Flash Plus button; 5 x USB 3.2 Gen 2 Type-A ports (red); 2 x USB Type-C® ports, with USB 3.2 Gen 2 support; 2 x USB4® USB Type-C® ports (DisplayPort (Note)); 1 x RJ-45 port; 3 x USB 3.2 Gen 1 ports; 2 x antenna connectors (2T2R); 2 x audi
Памет, кит
двуканален
Поддържани процесори
AMD Socket AM5, поддържа for:; AMD Ryzen™ 9000 Series Processors/; AMD Ryzen™ 8000 Series Processors/; AMD Ryzen™ 7000 Series Processors
GB X870 4xDDR5 4xSATA3 RAID HDMI 4xM2 GLAN 3xPCIEx16 WiFi
| Характеристики | |
| BIOS | 1 x 512 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| WiFi скорост | 2.5 Gbps, 100 Mbps |
| WiFi стандарт | 802.11a |
| WiFi честота | 2.4 GHz, 5 GHz, 6 GHz |
| Видео изходи | Integrated Graphics Processor with AMD Radeon™ Graphics support+ASMedia USB4® Controller:; - 2 x USB4® USB Type-C® ports, supporting USB4 and DisplayPort video outputs and a maximum resolution of 3840x2160@240 Hz; * Support for DisplayPort 1.4 version and HDR; Integrated Graphics Processor with AMD Radeon™ Graphics support:; - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz; * Support for HDMI 2.1 version, HDCP 2.3, and HDR.; ** Support for native HDMI 2.1 TMDS compatible ports.; - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz; * Support for HDMI 1.4 version |
| Видео карта, серия | Radeon Graphics |
| Входове/изходи | iTE® I/O Controller Chip |
| Конектори | 1 x 24-pin ATX main power connector; 2 x 8-pin ATX 12V power connectors; 1 x PCIe power connector; 1 x CPU fan header; 1 x CPU fan/water cooling pump header; 4 x system fan headers; 2 x system fan/water cooling pump headers; 3 x addressable RGB Gen2 LED strip headers; 1 x RGB LED strip header; 4 x SATA 6Gb/s connectors; 4 x M.2 Socket 3 connectors; 1 x front panel header; 1 x front panel audio header; 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support; 2 x USB 3.2 Gen 1 headers; 2 x USB 2.0/1.1 headers; 1 x noise detection header; 1 x HDMI port (Note); 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only); 2 x temperature sensor headers; 1 x reset jumper; 1 x Clear CMOS jumper; Back Panel Connectors; 1 x HDMI port (Note); 1 x reset button; 1 x power button; 1 x Clear CMOS button; 1 x Q-Flash Plus button; 5 x USB 3.2 Gen 2 Type-A ports (red); 2 x USB Type-C® ports, with USB 3.2 Gen 2 support; 2 x USB4® USB Type-C® ports (DisplayPort (Note)); 1 x RJ-45 port; 3 x USB 3.2 Gen 1 ports; 2 x antenna connectors (2T2R); 2 x audi |
| Памет, кит | двуканален |
| Поддържани процесори | AMD Socket AM5, поддържа for:; AMD Ryzen™ 9000 Series Processors/; AMD Ryzen™ 8000 Series Processors/; AMD Ryzen™ 7000 Series Processors |
| Производител | GIGABYTE |
| Слотове за разширение | 1 x PCI Express x16 слот (PCIEX16), integrated in the CPU:; AMD Ryzen™ 9000/7000 Series Processors поддържа PCIe 5.0 x16 mode; AMD Ryzen™ 8000 Series-Phoenix 1 Processors поддържа PCIe 4.0 x8 mode; AMD Ryzen™ 8000 Series-Phoenix 2 Processors поддържа PCIe 4.0 x4 mode; * The PCIEX16 слот can only поддържа a graphics card or an NVMe SSD. If only one graphics card is до be installed, be sure до install it in the PCIEX16 слот.; Chipset:; - 1 x PCI Express x16 слот, supporting PCIe 4.0 and running at x4 (PCIEX4); - 1 x PCI Express x16 слот, supporting PCIe 3.0 and running at x2 (PCIEX2) |
| Съхранение | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/ 22110/ 2580/ 2280 SSDs:; AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs; AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs; AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs; 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:; AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs; 2 x M.2 connectors (M2C_SB, M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSDs; 4 x SATA 6Gb/s connectors; RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices; * RAID 5 is only available on AMD Ryzen™ 9000 Series Processors; RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| Твърд диск, интерфейс | NVMe |
| Тип продукт | Дънна платка |
| Функции | Support for GIGABYTE Control Center (GCC); Support for Q-Flash; Support for Q-Flash Plus; Support for Smart Backup |
| Форм-фактор | ATX форм-фактор; 30.5 см x 24.4 см |
| Процесор, серия | AMD Ryzen 9, AMD Ryzen 7 |
| Чипсет | AMD X870E |
| Памет, тип | DDR5 |
| Твърд диск, тип | SSD |
| Операционна система | Support for Windows 11 64-bit; windows 11 |
| Мрежа | Realtek® 5GbE LAN chip (5 Gbps/2.5 Gbps/1 Gbps/100 Mbps) |
| Bluetooth | Bluetooth 5.4 |
| USB | CPU+ASMedia USB4® controller:; - 2 x USB4® USB Type-C® ports on the back pane; CPU:; - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support; Chipset+USB 3.2 Gen 1 Hub:; - 4 x USB 3.2 Gen 1 ports available through the internal USB headers; Chipset:; - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header (Supports up to 65W PD 3.0/QC 4+ fast charging); * For precautions regarding the fast charging function, refer to "USB Type-C® Header" in Chapter 2-7, "Internal Connectors."; - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support; - 5 x USB 3.2 Gen 2 Type-A ports (red) on the back panel; - 3 x USB 3.2 Gen 1 ports on the back panel; - 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Аудио | Realtek® ALC1220 CODEC; * The back panel line out jack supports DSD audio.; High Definition Audio; 2/4/5.1/7.1-channel; * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.; Support for S/PDIF Out |
НАЛИЧНОСТ: Външен доставчик
📦 Продуктът не е в локален склад, а се намира при външен партньор или доставчик. Това може да има няколко последствия:
⏱️ По-дълъг срок за доставка – често се изисква допълнително време за получаване и препращане.
✅ Продуктът може да бъде поръчан, но не е наличен за моментално получаване в магазина .
🔹 Наш сътрудник ще се свърже с Вас, когато продуктът бъде наличен за взимане от магазина или готов за доставка.
